SFL100 5km Drone Detection Radar with 24GHz Phased Array Antenna

  • 1
  • 2
  • 3

Brand Name : OEM

Model Number : SSH100

Certification : ccc

Place of Origin : China

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Packaging Details : Air box packaging

Detection Frequency : 24GHz

Target Detection : Single drones or swarms

Antenna Rotation : 360 Degrees

Target Velocity : Up to 100 km/h

Model No : CI3000

Specification : Ku Band

Antenna Type : Phased Array

Installation Method : Formal/Car/Tripod Stand

Antenna Gain : 20 dBi

Detection Power : >= 5km (Rcs=0.0m²)

Field Of View : 360°

Distance Accuracy : 8m

Scan Rate : Up to 30 scans per second

User Interface : User-friendly and intuitive interface

Installation Mode : Ground Steel Bracket or Tripod

Contact Now

Tracker SDH100 is a compact, low-SWaP K-band FMCW phased array radar delivering all-weather beyond-line-of-sight (BLOS) 4D detection of aerial and ground targets. Capable of tracking nano drones from 500m, vehicles up to 4km, and humans at 2.2km, it offers high-refresh-rate precision guidance for optical and countermeasure systems.

Weighing only 3kg and deployable in 3 minutes, Tracker supports portable, vehicle-mounted, airborne, and fixed-site operations. Its RF-stealth design, 100°×45° field of view, and support for multi-node networking make it ideal for critical area protection, convoy security, UAV collision avoidance, and integration with automated C-UAS solutions like SkyShield.

Designed for high mobility and rapid response across complex environments, Tracker provides cost-effective, continuous air-ground awareness for defense and security applications.

SFL100 5km Drone Detection Radar with 24GHz Phased Array AntennaSFL100 5km Drone Detection Radar with 24GHz Phased Array AntennaSFL100 5km Drone Detection Radar with 24GHz Phased Array Antenna
